Stainless Steel Pig Nipple Waterer – G 1/2” or NPT 1/2” Thread Automatic Pig Water Drinker for Piglets & Swine Farms
Features:
G-1/2″ Thread (European pipe thread) or NPT-1/2″ (American pipe thread) is favorable.
Body length 63.5mm.
Pressure cone diameter 22mm.
Weight 86g.
With diameter 8mm pin.
Adjustable plastic filter with stainless steel netting.
Adjustable plastic filter is easy to change high pressure water systems and low pressure water systems.
NBR 90 O-ring is permanent and protect leaking.
Product Description:
The drinking fountain is an automatic duckbill nipple drinker for pigs. It is an indispensable drinking water device in the modern pig farm in the drinking water system. The kind of pig stainless steel duckbill type nipple drinker is with different size.
Animal pig nipple water drinker consists of valve body, valve plug, sealing ring, return spring, corking, sieve, etc. The valve body and valve plug are made of brass and stainless steel, the return spring and corking are made of stainless steel, and the sieve is made of engineering plastics. The overall structures are simple and corrosion-resistant.
Application of animal pig Nipple water drinker
There’re two kinds of duck-billed pig drinker, the small one with flow of 2-3L/min, and the big one with flow of 3-4L/min. The small one is suit for piglet, and the big one is suit for fattening pig and adult pig.
Product Information
| Name | Pig Water Drinkers |
| Model | NP-802 |
| Length | 63.5mm |
| Stem | 22x8mm |
| Weight | 86g |
| Inlet | G – 1/2’’ thread or NPT – 1/2’’ is favorable |
| LOGO | Laser logo or stamping logo is favorable |
| O-ring | NBR 90 |
| Shape | Straight, (45, 90, 70) degrees, T shape, two way type, long type, square type and other special customized type |
| Surface | Zinc (chrome, copper and nickel are available) |
| Main of material | Carbon steel, mild steel, brass etc. |
| Package |
1. Inner packing: OPP bags, 100pcs/bag with a sticker, stickers can be printed as per buyer’s requirements 2. Outer packing: standard export cardboard cartons and reinforced with straps 3. Other customized packing ways negotiable |
| MOQ | 1000PCS |
| Payment | T/T |
